Installing the Series 5400zl Switches
Example Network Topologies
Installing the Series 5400zl
Switches
Example Network Topologies
This section shows a few example network topologies in which the Series
5400zl Switches can be implemented. Although these examples show the
6-slot chassis, the principles are the same for the 12-slot chassis.
Basic Connectivity
Figure 2-15. Basic Switch Connectivity
The Series 5400zl Switches can provide basic network connectivity to a high
number of PoE devices. These devices can be easily connected, as shown in
the above illustration.
Series 5400zl Switch
Phones, APs and other peripherals
