1-14
Introducing the ProCurve Series 5400zl Switches
Switch Features
Introducing the ProCurve
Series 5400zl Switches
Switch Features
The features of the Series 5400zl Switches include:
■ 6 or 12 slots for installing any of the available Switch zl Modules.
Supported Modules: As of this printing, the supported zl modules
include:
• 24-port 10/100/1000-T zl PoE Module (J8702A) -- which can provide
Power over Ethernet (PoE) power to 802.3af compliant (and some
pre-standard) devices. For more information on PoE power refer to
the PoE (Power over Ethernet) Planning and Implementation
Guide. For more information on the J8702A module refer to the
ProCurve Switch zl Modules Installation Guide
• 20-port Gig-T and 4-port mini-GBIC/SFP zl PoE Module (J8705A)-- into
which you can install the supported mini-GBICs and SFP transceivers:
• Gigabit-SX LC mini-GBIC (J4858B)
• Gigabit-LX LC mini-GBIC (J4859B)
• Gigabit-LH LC mini-GBIC (J4860B)
• 1000Base-T mini-GBIC (J8177B)
• 100-FX SFP-LC transceiver (J9054B)
• 24-port mini-GBIC zl Module (J8706A) -- into which you can install the
supported mini-GBICs or SFPs, see above
• 4-port 10Gig-X2 zl Module (J8707A) -- into which you can install the
supported X2 fiber optic transceivers:
• 10 Gigabit-X2-SC SR Optic transceiver (J8436A)
• 10 Gigabit-X2-SC LR Optic transceiver (J8437A)
• 10 Gigabit-X2-SC ER Optic transceiver (J8438A)
• 10 Gigabit-X2-SC LRM Optic transceiver (J9144A)
• 10 Gigabit-X2-CX4 copper transceiver (J8440B)
• 10 Gigabit-X2-CX4 Optical Media Converter (J8439A)
• 4-port 10Gig-CX4 zl Module (J8708A)
• Wireless Edge Services zl Module (J9051A) and Redundant Wireless
Services zl Module (J9052A)
• Services zl Module (J9154x) where “x” is the version letter A, B, and
so on
■ modules can be installed in any order and in any combination and can the
“hot swapped”
■ supported mini-GBICs can be hot swapped into the mini-GBIC zl Module
