HP b2600 Supplementary Guide

16 Chapter1
Remove/Replace System Components
Removing/Replacing System Components
Removing Memory DIMMs
This section explains how to remove DIMM cards from your workstation. Please refer to
the subsequent “Memory Configuration” section for the proper sequencing of DIMM cards
in the system board’s memory slots.
Here is the procedure for removing DIMM cards from your workstation:
1. Complete the procedure in the section “Removing the Front Bezel and Top Cover”
found in this chapter.
2. Press downward on the tabs that are located on both ends of the memory card slots. See
Figure 1-3.
Figure 1-3. Pressing Down on the Memory Slot Tabs
3. Grasp both edges of the DIMM card and lift it out of the memory slot. See Figure 1-4.
Figure 1-4. Lifting a DIMM Card Out of the Memory Slot
Memory Slot
Tab
DIMM Card
Slots
DIMM Card
