HP b2600 Supplementary Guide

Appendix B
DC Power Supply
Removing the DC Power Supply
79
Removing the DC Power Supply
This section explains how to remove your workstation’s DC power supply. Please keep in mind that
the reverse of the steps given in this section should be used to replace the DC power supply.
The following procedure explains how to remove your DC power supply.
1. Remove the DC connector cap located on the back side of your workstation. See Figure B-2.
Figure B-2 Removing the DC Connector Cap
2. Disconnect the power source cables from the system as stated in the WARNING at the beginning
of this chapter. See Figure B-3
Figure B-3 Disconnecting the DC Power Source
DC Connector Cap
Power Source Cables
