Performance Tests
HP E-Series Power Sensor Functional Test
HP EPM-441A/442A Service Guide 2-15
HP E-Series Power Sensor Functional Test
Description
This test verifies that the meter/sensor combination can make RF
measurements.
The HP E-series power sensors operate over a 90 dB dynamic range
(-70 to +20 dBm). However, since there is an amplifier in these power
sensors, the voltages presented to the power sensor connector are always
within the range of voltages available from the HP 11683A range
calibrator.
Equipment
Power Sensor Cable .............................. HP 11730A
Reference Attenuator ............................ HP 11708A
HP E-series power sensor
4402serv.book Page 15 Monday, March 11, 2002 11:34 AM
