326
# Configure static routes to 192.168.64.0/24, 192.168.74.0/24, and 192.168.99.0/24 with the
same next hop 192.168.212.161 on Switch B.
<SwitchB> system-view
[SwitchB] ip route-static 192.168.64.0 24 192.168.212.161
[SwitchB] ip route-static 192.168.74.0 24 192.168.212.161
[SwitchB] ip route-static 192.168.99.0 24 192.168.212.161
3. Configure OSPF between Switch B and Switch C and configure OSPF on Switch B to
redistribute static routes:
# Configure OSPF to advertise the local network and enable OSPF to redistribute static routes
on Switch B.
[SwitchB] ospf
[SwitchB-ospf-1] area 0
[SwitchB-ospf-1-area-0.0.0.0] network 172.17.100.0 0.0.0.255
[SwitchB-ospf-1-area-0.0.0.0] quit
[SwitchB-ospf-1] import-route static
[SwitchB-ospf-1] quit
# Configure OSPF to advertise the local networks on Switch C.
[SwitchC] ospf
[SwitchC-ospf-1] area 0
[SwitchC-ospf-1-area-0.0.0.0] network 172.17.100.0 0.0.0.255
[SwitchC-ospf-1-area-0.0.0.0] network 10.220.2.0 0.0.0.255
[SwitchC-ospf-1-area-0.0.0.0] quit
[SwitchC-ospf-1] quit
# Display the IP routing table on Switch C.
[SwitchC] display ip routing-table protocol ospf
Summary count : 5
OSPF Ro
uting ta
ble St
atus : <Ac
tive>
Summary count : 3
Destination/Mask Proto Pre Cost NextHop Interface
192.168.64.0/24 OSPF 150 1 172.17.100.1 Vlan100
192.168.74.0/24 OSPF 150 1 172.17.100.1 Vlan100
192.168.99.0/24 OSPF 150 1 172.17.100.1 Vlan100
OSPF Routing table Status : <Inactive>
Summary count : 2
Destination/Mask Proto Pre Cost NextHop Interface
10.220.2.0/24 OSPF 10 1 10.220.2.16 Vlan200
172.17.100.0/24 OSPF 10 1 172.17.100.2 Vlan100
The output shows that Switch C has learned routes to 192.168.64.0/24, 192.168.99.0/24, and
192.168.64.0/18 through OSPF.
4. Configure BGP between Switch C and Switch D and configure BGP on Switch C to redistribute
OSPF routes:
# On Switch C, enable BGP, specify Switch D as an EBGP peer, and configure BGP to
redistribute OSPF routes.
[SwitchC] bgp 65106
