Install the server components
This section contains the following topics:
• Electrostastic discharge on page 13
• Shipping carton contents on page 13
• Components not supplied in the shipping carton on page 14
• Rack requirements on page 14
• Rack installation guidelines on page 14
• Install the server in a rack on page 15
• Connect the power cables on page 15
• Connect the network cables on page 16
• Organize the cables on page 17
• Power up the server on page 17
To install the server components, you must unpack all components, install the server in a rack, connect the power and network
cables, and power on the system.
Electrostastic discharge
You must protect sensitive components from electrostatic discharge (ESD).
To protect components from ESD:
• Ensure the component is fully grounded at all times to prevent damage from electrostatic discharge.
• When not installed in a rack, store server components in the original packaging or place on a sturdy surface that is protected
from electrostatic discharge.
• When handling server components, always use the electrostatic wrist strap provided or a similar form of ESD protection.
Shipping carton contents
The shipping carton contains standard items and other items based on your configuration.
DescriptionPart
Provides processing power and storage capacity.Server
Protects the SSD and HDD drives in the front panel.Bezel
• Two standard power cords.
• Two IEC C13/C14 (PDU) cords.
Power cords
Contains the left and the right rails and detailed installation
documentation.
Rack-mounting hardware (optional)
Contains the CMA assembly and installation documentation.Cable Management Arm (CMA) kit (optional)
• Hardware Installation Quick Start
• Configuration and Deployment Quick Start
• Product Information Guide (safety and regulatory notices)
• End User License Agreement
Printed documentation
Install the server components 13
