DescriptionItemCallout
The HPE SimpliVity 380 Gen10 H small
form factor (SFF) server is fully populat-
ed with 24 drives in the following config-
uration:
• Drive boxes are numbered 1-3 from
left to right.
• Each drive box contain a maximum
of 8 drive slots.
• Drive slots are number 1-24 from left
to right.
• Drive slots are numbered 1-8 (drive
box 1), 9-16 (drive box 2), and 17-
24 (drive box 3).
• Drive slots 1-4 contain SSDs, drive
slots 5-24 contain HDDs.
Drive boxes 1-3Drive boxes (continued)
Note:
When the Power, Health, NIC status, and UID LEDs flash simultaneously, a power fault has occurred. For more
information, see "Power fault LEDs" in the HPE ProLiant DL380 Gen10 Server User Guide.
Back panel components
The back panel of an HPE SimpliVity 380 server contains the Accelerator card, network and device ports, power supplies, and
boot drives.
