Physical dimensions
For the physical specification of the drive, see Chapter 2, “Physical Specification” in the Ultrium LTO-8
Tape Drives Technical Reference Manual Volume 4 Specifications Guide.
Requirements
• M3 threaded screws are required.
• The recommended mounting torque for Half-height drives is:
3.5 +/-10% lb-in (0.4 +/- 10% Nm)
• HPE recommends 0.3 mm mounting clearance around all covers for isolation mounting movement.
Half-height drives
Mounting Points Maximum Screw Penetration
Side - upper 2.5 mm
Side - lower 5.0 mm
Bottom 5.0 mm
6 Physical dimensions
