Hardware options installation 28
• DIMM configuration on channel 1 and channel 2 of a processor must be identical.
• In multi-processor configurations, each processor must have a valid Lockstep Memory configuration.
• In multi-processor configurations, each processor may have a different valid Lockstep Memory
configuration.
Single-processor Lockstep population order
For Lockstep memory mode configurations with a single processor, populate the DIMM slots in the
following order:
• RDIMM
o First: A and B
o Next: D and E
o Do not populate slots C or F.
• UDIMM
o First: A and B
o Last: D and E
o Do not populate slots C or F.
After installing the DIMMs, use RBSU to configure the system for Lockstep memory support.
Multi-processor Lockstep population order
For Lockstep memory mode configurations with multiple processors, populate the DIMM slots for each
processor in the following order:
• RDIMM
o First: A and B
o Next: D and E
o Do not populate slots C or F.
• UDIMM
o First: A and B
o Last: D and E
o Do not populate slots C or F.
After installing the DIMMs, use RBSU to configure the system for Lockstep memory support.
Installing DIMMs
CAUTION: To avoid damage to the hard drives, memory, and other system components, the
air baffle, drive blanks, and access panel must be installed when the server is powered up.
1. Power down the server (on page 7).
2. For ML110 G6 servers, extend the server from the rack.
3. For ML150 G6 servers, do one of the following:
o Unlock and remove the bezel ("Remove the tower bezel (ML150 G6 servers)" on page 8).

HP ML150 - ProLiant - G6 Specifications

General

Product Line	ProLiant
Model	ML150 G6
Processor Sockets	2
Form Factor	Tower
Chipset	Intel 5520
Hard Drive Form Factor	3.5-inch
Processor	Intel Xeon 5500 series
Memory	Up to 48GB DDR3
Memory Slots	12
Expansion Slots	6
Power Supply	750W
Number of Processors Supported	1 or 2 (depending on model)
