HP ML150 - ProLiant - G6 User Manual

Troubleshooting 55
• OS boot problems flowchart (on page 61)
• Server fault indications flowchart (on page 62)
Start diagnosis flowchart
Use the following flowchart and table to start the diagnostic process.
Item See
1 "General diagnosis flowchart (on page 55)"
2 "Power-on problems flowchart (on page 57)"
3 "POST problems flowchart (on page 59)"
4 "OS boot problems flowchart (on page 61)"
5 "Server fault indications flowchart (on page 62)"
General diagnosis flowchart
The General Diagnosis flowchart provides a generic approach to troubleshooting. If you are unsure of the
problem, or if the other flowcharts do not correct the problem, use the following flowchart.

HP ML150 - ProLiant - G6 Specifications

General

Product Line	ProLiant
Model	ML150 G6
Processor Sockets	2
Form Factor	Tower
Chipset	Intel 5520
Hard Drive Form Factor	3.5-inch
Processor	Intel Xeon 5500 series
Memory	Up to 48GB DDR3
Memory Slots	12
Expansion Slots	6
Power Supply	750W
Number of Processors Supported	1 or 2 (depending on model)
