6 Removal and replacement procedures for
authorized service provider parts
This chapter provides removal and replacement procedures for authorized service provider parts.
IMPORTANT: Components described in this chapter should be accessed only by an authorized service
provider. Accessing these parts can damage the computer or void the warranty.
NOTE: Details about your computer, including model, serial number, product key, and length of warranty,
are on the service tag at the bottom of your computer.
Component replacement procedures
To remove and replace computer components, use these procedures.
NOTE: HP continually improves and changes product parts. For complete and current information about
supported parts for your computer, go to http://partsurfer.hp.com, select your country or region, and then
follow the on-screen instructions.
You must remove, replace, or loosen as many as 56 screws when you service the parts described in this
chapter. Make special note of each screw size and location during removal and replacement.
Battery
To remove the battery, use this procedure and illustration.
Table
6-1 Battery description and part number
Description Spare part number
Battery, 6 cell, 70 Wh L84392-006
Battery, 3 cell, 52 Wh L84394-006
WARNING! To avoid personal injury and damage to the product:
● Do not puncture, twist, or crack the battery.
● Do not cause an external puncture or rupture to the battery. They can cause a short inside the battery,
which can result in battery thermal runaway.
● Do not handle or touch the battery enclosure with sharp objects such as tweezers or pliers, which might
puncture the battery.
● Do not compress or squeeze the battery case with tools or heavy objects stacked on top of the case.
These actions can apply undue force on the battery.
● Do not touch the connectors with any metallic surface or object, such as metal tools, screws, or coins,
which can cause shorting across the connectors.
Before removing the battery, follow these steps:
37
