4–4 Hardware and Software Guide
Multimedia
Using the Audio-In (Microphone) Jack
The audio-in jack, identified in the following illustration,
connects an optional monaural (single sound channel)
microphone. The audio-in jack is sometimes called a
microphone jack.
It is recommended that you use an electret condenser microphone
with a 3.5-mm plug. If you connect a dynamic microphone, the
recommended sensitivity may not be achieved.
External Video Devices
Connecting an S-Video Device
(Select
Models Only)
Connecting the Audio
The S-Video-out jack (select models only) supports video
signals only.
If you are setting up a configuration that combines audio and
video functions, such as playing a DVD movie on your notebook
and displaying it on your television, you need a standard 3.5-mm
audio cable available from most computer or electronics retailers.
