11-22
Configuring Advanced Threat Protection
Dynamic ARP Protection
Figure 11-1. The show arp-protect Command
Displaying ARP Packet Statistics
To display statistics about forwarded ARP packets, dropped ARP packets,
MAC validation failure, and IP validation failures, enter the show arp-protect
statistics <vid-range> command:
Figure 11-2. Show arp-protect statistics Command
ARP Protection Information
Enabled Vlans : 1-4094
Validate : dest-mac, src-mac
Port Trust
----- -----
B1 Yes
B2 Yes
B3 No
B4 No
B5 No
HP Switch(config)# show arp-protect
HP Switch(config)# show arp-protect statistics 1-2
Status and Counters - ARP Protection Counters for VLAN 1
Forwarded pkts : 10 Bad source mac : 2
Bad bindings : 1 Bad destination mac: 1
Malformed pkts : 0 Bad IP address : 0
Status and Counters - ARP Protection Counters for VLAN 2
Forwarded pkts : 1 Bad source mac : 1
Bad bindings : 1 Bad destination mac: 1
Malformed pkts : 1 Bad IP address : 1
