HP ProCurve 6200yl Series User Manual

12-23
Traffic/Security Filters and Monitors
Configuring Traffic/Security Filters
Figure 12-16. Example of Displaying Filter Data
HP Switch(config)# show filter
Traffic/Security Filters
IDX Filter Type | Value
--- ------------ + --------------
1 Source Port | A1
2 Source Port | A2
3 Multicast | 010000-123456
4 Multicast | 010000-224466
5 Protocol | Appletalk
6 Protocol | ARP
HP Switch(config)# show filter 4
Traffic/Security Filters
Filter Type : Multicast
Multi-cast Addres : 010000-224466
Dest Port Type | Action
--------- --------- + -------
A1 1000LX | Forward
A2 | Forward
A3 | Forward
A4 1000SX | Forward
B1 100/1000T | Drop
B2 100/1000T | Drop
B3 100/1000T | Drop
B4 100/1000T | Drop
C1 10/100TX | Forward
C2 10/100TX | Forward
C3 10/100TX | Forward
. . .
Filter Index Numbers
(Automatically Assigned)
Lists all filters configured
in the switch.
Uses the index number
(IDX) for a specific filter
to list the details for that
filter only.
Criteria for Individual
Filters
