HP ProLiant ML370 G6 User Manual

Component identification 21
Green LED Amber LED Interpretation
Flashing (2 Hz)
Alternating with
amber LED
Flashing (2 Hz)
Alternating with
green LED
One of the following conditions exists:
•
The charging process has timed out.
•
The capacitor pack is not connected.
On
On The flash code image failed to load.
Off
Off The flash code is corrupt.
Power supply backplane connectors
Item Description
BP1
Drive bay 1 power cable
BP2
Drive bay 2 power cable
BP3
Drive bay 3 power cable
P1
Power supply 1 cable
P2
Power supply 2 cable
P6
SATA power cable
P7
SATA power cable
P8
SATA power cable
P9
Video adapter power cable
P10
Data cable
P12
Video adapter power cable
Drive cage jumper configuration settings
Drive cage Installation Pin setting
1
Standard No jumper
2
Optional 1-2*
3
Optional 2-3
*Optional drive cages ship with the jumper set across pins 1 and 2.
