Hardware options installation 86
6.
Install the cache module.
7. Install the access panel.
8. Do one of the following:
o Close or install the tower bezel, as needed.
o Slide the server back into the rack.
9. Power up the server (on page 22, "Powering up and configuring the server" on page 40).
Installing the BBWC battery pack or the FBWC capacitor pack
CAUTION: Do not use this controller with cache modules designed for other controller models,
because the controller can malfunction and you can lose data. Also, do not transfer this cache
module to a different controller module, because you can lose data.
To install the component:
1. Back up all data.
2. Close all applications.
3. Power down the server (on page 22).
CAUTION: In systems that use external data storage, be sure that the server is the first unit to be
powered down and the last to be powered back up. Taking this precaution ensures that the system
does not erroneously mark the drives as failed when the server is powered up.
4. Do one of the following:
o Unlock and remove the bezel ("Open or remove the tower bezel" on page 22).
o Extend the server from the rack (on page 24).
5. Remove the access panel (on page 25).
6. Install the cache module ("Installing the cache module" on page 85).
7. Install the storage controller ("Storage controller option" on page 84), if not already installed.
