HP ProOne 600 G3 User Manual

Power supply
The power supply is located under the VESA mounting bracket.
To remove the power supply:
1. Prepare the computer for disassembly (see Preparing to disassemble the computer on page 19).
2. Remove the rear port cover (see Rear port cover on page 23).
3. Remove the stand (see Attaching and removing a stand on page 20).
4. Remove the access panel (see Access panel on page 24).
5. Remove the VESA mounting bracket (see VESA mounting bracket on page 43).
6. Disconnect the cable from the system board (1).
7. Lift the power supply out the computer (2).
To replace the VESA mounting bracket, reverse the removal procedures.
44 Chapter 4 Removal and Replacement Procedures
