Speakers
The speakers are located at the bottom of the computer. Two separate speakers are each secured by two Torx
screws.
To remove the speakers:
1. Prepare the computer for disassembly (see Preparing to disassemble the computer on page 19).
2. Remove the rear port cover (see Rear port cover on page 23).
3. Remove the stand (see Attaching and removing a stand on page 20).
4. Remove the access panel (see Access panel on page 24).
5. Remove the system board shield (see System board (EMI) shield on page 30).
6. Remove the feet, rear I/O cover, and bottom panel (see Feet, rear I/O bracket, and bottom panel
on page 52).
7. Disconnect the speaker cable from the system board (1).
8. Remove two Torx screws (2) that secure each speaker to the computer.
9. Remove speaker cable from the clips and routing path built into the chassis (3), and then remove the
speakers from the computer.
10. Remove the speakers from the computer.
To install the speakers, reverse the removal procedures.
54 Chapter 4 Removal and Replacement Procedures
