HP ProOne 600 G3 User Manual

Right trim
To remove the right trim:
1. Prepare the computer for disassembly (see Preparing to disassemble the computer on page 19).
2. Remove the rear port cover (see Rear port cover on page 23).
3. Remove the stand (see Attaching and removing a stand on page 20).
4. Remove the access panel (see Access panel on page 24).
5. Remove the system board shield (see System board (EMI) shield on page 30).
6. Remove the top trim (see Top trim on page 47).
7. Remove the four Torx screws (1) that secure the right trim to the computer, and then rotate the trim
away from the computer to remove (2).
To install the right trim, reverse the removal procedures.
50 Chapter 4 Removal and Replacement Procedures
