Computer Setup—Storage
Option Description
Device
Configuration
Lists all installed BIOS-controlled storage devices. When a device is selected, detailed information
and options are displayed. The following options may be presented:
Hard Disk: Size, model, firmware version, serial number.
Storage Options SATA Emulation
CAUTION: SATA emulation changes may prevent access to existing drive data and degrade or
corrupt established volumes.
Allows you to choose how the SATA controller and devices are accessed by the operating system.
There are two supported options: IDE and AHCI (default).
IDE - This is the most backwards-compatible setting of the three options. Operating systems usually
do not require additional driver support in IDE mode.
AHCI (default option) - Allows operating systems with AHCI device drivers loaded to take
advantage of more advanced features of the SATA controller.
DPS Self-test Allows you to execute self-tests on ATA hard drives capable of performing the Drive Protection
System (DPS) self-tests.
NOTE: This selection will only appear when at least one drive capable of performing the DPS self
tests is attached to the system.
Boot Order Allows you to:
ł
Specify the order in which EFI boot sources (such as a internal drive, USB hard drive, or USB
optical drive) are checked for a bootable operating system image. Each device on the list may
be individually excluded from or included for consideration as a bootable operating system
source. EFI boot sources always have precedence over legacy boot sources.
ł
Specify the order in which legacy boot sources (such as a network interface card, internal
drive, or USB optical drive) are checked for a bootable operating system image. Each device
on the list may be individually excluded from or included for consideration as a bootable
operating system source.
ł
Specify the order of attached hard drives. The first hard drive in the order will have priority in
the boot sequence and will be recognized as drive C (if any devices are attached).
NOTE: You can use F5 to disable individual boot items, as well as disable EFI boot and/or
legacy boot.
MS-DOS drive lettering assignments may not apply after a non-MS-DOS operating system has
started.
Shortcut to Temporarily Override Boot Order
To boot one time from a device other than the default device specified in Boot Order, restart the
computer and press Esc (to access the boot menu) and then F9 (Boot Order), or only F9 (skipping
the boot menu) when the monitor light turns green. After POST is completed, a list of bootable
devices is displayed. Use the arrow keys to select the preferred bootable device and press Enter.
The computer then boots from the selected non-default device for this one time.
Computer Setup (F10) Utilities
35

HP t620 Specifications

General

L2 cache	1 MB
Processor cores	2
Processor model	GX-217GA
Processor family	AMD G
Motherboard chipset	-
Processor frequency	1.65 GHz
Storage media	SSD
Card reader integrated	No
Total storage capacity	32 GB
Internal memory	4 GB
Memory clock speed	1600 MHz
Internal memory type	DDR3L-SDRAM
On-board graphics card model	AMD Radeon HD 8280E
Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
USB 2.0 ports quantity	6
Ethernet LAN (RJ-45) ports	1
VGA (D-Sub) ports quantity	0
Operating system installed	Windows Embedded 8 Standard
Operating system architecture	64-bit
Product color	Black
Power supply	65 W
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Country of origin	China

Weight and Dimensions

Depth	40 mm
Width	220 mm
Height	240 mm
Weight	1360 g
