HP t620 User Manual

E Adding an Image Restore Tool
1. Ensure that the boot order is set to use the Network as the first boot device.
2. Ensure that IBR.exe (Image Restore) and Flash.dd are stored in the same directory on the server.
(e.g., c:\program files\altiris\express\deployment server\images)
3. From the Altiris Deployment Server Console, click File > New > Job .
4. Enter a unique name for the job that you will use to deploy the original thin client image.
5. Click the name of the new job.
6. Near the upper right side of the screen, click Add.
7. Select Run Script from the menu.
8. Type [full path]images\ibr\exe-y\images\flash.xx hd0
NOTE: Linux uses the file name FLASH.DD while other operating system images use FLASH.IMG
9. Under In which OS would you like to run this script? Click DOS.
10. Click Finish.
11. You can now drag and drop the job onto the appropriate machine(s) or schedule it to run later,
depending on your needs. Refer to the documentation for Altiris Deployment Solution
(
http://www.altiris.com/support/documentation) for more detailed information.
58 Appendix E Adding an Image Restore Tool

HP t620 Specifications

General

L2 cache	1 MB
Processor cores	2
Processor model	GX-217GA
Processor family	AMD G
Motherboard chipset	-
Processor frequency	1.65 GHz
Storage media	SSD
Card reader integrated	No
Total storage capacity	32 GB
Internal memory	4 GB
Memory clock speed	1600 MHz
Internal memory type	DDR3L-SDRAM
On-board graphics card model	AMD Radeon HD 8280E
Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
USB 2.0 ports quantity	6
Ethernet LAN (RJ-45) ports	1
VGA (D-Sub) ports quantity	0
Operating system installed	Windows Embedded 8 Standard
Operating system architecture	64-bit
Product color	Black
Power supply	65 W
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Country of origin	China

Weight and Dimensions

Depth	40 mm
Width	220 mm
Height	240 mm
Weight	1360 g
