HP t620 User Manual

I Specifications
Dimensions
Width: HP t620 Thin Client
Width: HP t620 PLUS Thin Client
Depth
Height (without stand)
Height (with stand)
40 mm
65 mm
240 mm
219.70 mm
220 mm
1.57 in.
2.56 in.
9.45 in
8.65 In
8.66 in.
Temperature Range (fanless design)*
Operating**
With the fiber NIC is installed
(max. rate of change is 10°C per hour or 18°F per hour)
Nonoperating
(max. rate of change is 20°C per hour or 36°F per hour)
10°C to 40°C
10°C to 35°C
-30°C to 60°C
50°F to 104°F
50°F to 95°F
-22°F to 140°F
*Specifications are at sea level with altitude derating of
1°C/300 m (1.8°F/1000 ft) to a maximum of 3 Km
(10,000 ft), with no direct, sustained sunlight. Upper limit
may be limited by the type and number of options installed.
** The operating temperature range when the thin
client is attached to a flat panel using the HP Quick
Release is 10°C to 35°C (50°F to 95°F).
Relative Humidity (non-condensing)
Operating
(max. wet bulb temperature is 28°C or 84.2°F)
Nonoperating
(max. wet bulb temperature is 38.7°C or 101.6°F)
10% to 90%
5% to 95%
65

HP t620 Specifications

General

L2 cache	1 MB
Processor cores	2
Processor model	GX-217GA
Processor family	AMD G
Motherboard chipset	-
Processor frequency	1.65 GHz
Storage media	SSD
Card reader integrated	No
Total storage capacity	32 GB
Internal memory	4 GB
Memory clock speed	1600 MHz
Internal memory type	DDR3L-SDRAM
On-board graphics card model	AMD Radeon HD 8280E
Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
USB 2.0 ports quantity	6
Ethernet LAN (RJ-45) ports	1
VGA (D-Sub) ports quantity	0
Operating system installed	Windows Embedded 8 Standard
Operating system architecture	64-bit
Product color	Black
Power supply	65 W
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Country of origin	China

Weight and Dimensions

Depth	40 mm
Width	220 mm
Height	240 mm
Weight	1360 g
