Setting Up the Monitor

3–2 User’s Guide

Unfolding the double-hinged monitor

WARNING: Do not place the double-hinged monitor face down for folding. The base hinge can spring up and

cause serious injury or damage.

1. With the monitor still in its flat, folded state, set it screen-side up on a flat surface.

2. Rotate the screen to the horizontal position (in the figure, the straight arrow is your position in front of the

monitor).

3. Holding the base of the monitor, lift up the panel at its top without touching or putting pressure on the screen (3).

4. Remove the shipping strap (do not cut it) (4).

5. Put the shipping strap in a safe place, in case you need it to ship the monitor.

6. Lift and lower the base hinge for proper viewing.

Questions and Answers:

Need help?

Do you have a question about the HP w2207 and is the answer not in the manual?

HP w2207 Specifications

General

Plug and Play	Yes
Height adjustment	No
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
Display diagonal	22 \
Display resolution	1680 x 1050 pixels
Contrast ratio (dynamic)	-
Contrast ratio (typical)	1000:1
Viewing angle, horizontal	160 °
Digital vertical frequency	48 - 76 Hz
Digital horizontal frequency	24 - 82 kHz
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	1680 x 1050 (WSXGA+)
Power consumption (standby)	2 W
Power consumption (typical)	65 W
Storage temperature (T-T)	20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
DVI-I ports quantity	0
RMS rated power	4 W
Number of speakers	2
Product color	Black
Country of origin	China
