Preparing the Monitor for Shipping
User’s Guide 5–3
Folding the Double-Hinged Monitor
You don’t have to remove this monitor base for shipping. Fold the double-hinged monitor in its original shipping
position.
Å
WARNING: Do not place the double-hinged monitor face down for folding. The base hinge can spring up and
cause serious injury or damage.
1. Turn the monitor to a horizontal position with no tilt.
2. Lower the monitor all the way until the hinge is flat.
The monitor screen should still be vertical to the desktop so you can access the hinge.
3. Place the shipping strap around the base, pull it tight, and connect it by sliding the strap ends through the slips.
4. Lower the monitor screen down flat, horizontal to the desktop.

HP w2207 Specifications

General

Plug and Play	Yes
Height adjustment	No
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
Display diagonal	22 \
Display resolution	1680 x 1050 pixels
Contrast ratio (dynamic)	-
Contrast ratio (typical)	1000:1
Viewing angle, horizontal	160 °
Digital vertical frequency	48 - 76 Hz
Digital horizontal frequency	24 - 82 kHz
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	1680 x 1050 (WSXGA+)
Power consumption (standby)	2 W
Power consumption (typical)	65 W
Storage temperature (T-T)	20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
DVI-I ports quantity	0
RMS rated power	4 W
Number of speakers	2
Product color	Black
Country of origin	China

Weight and Dimensions

Depth (without stand)	289 mm
Width (without stand)	523.5 mm
Height (without stand)	481.3 mm
Weight (without stand)	9000 g
