Figure 5-127 Holding the male and female unshielded connectors
Step 2 Feed the male connector into the female connector, as shown in Figure 5-128.
Figure 5-128 Feeding the male connector into the female unshielded connector
Step 3 A crisp click indicates that the connector is locked by the locking key. Pull the connector
slightly and ensure that it is securely connected. Figure 5-129 shows an installed Ethernet
connector.
Figure 5-129 Installed unshielded Ethernet connector
