FusionModule5000 Smart Modular Data Center
Maintenance Guide (ECC800)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
b. Select the user whose access permission needs to be modified and click Modify.
c. Reset the access actuator permission, cabinet lock permission, permission validity
period, and time period, and then click OK.
d. Choose System Settings > Access Right Management > Synchronize Permission.
Select the access control devices with modified permissions and synchronize the
access permissions.
5.5.19 Replacing an Access Control Device
Prerequisites
Tool ESD wrist strap, ESD gloves, flat-head screwdriver, Phillips screwdriver, labels,
and marker
Materials: a reserved undamaged and undeformed access control device of the
appropriate model
For details about how to replace a fingerprint and card reader, fingerprint and card reader
with a keypad, and card reader with a keypad, see Replacing an access control device.
For details about how to replace an IC card reader, see Procedure for Replacing an IC
Card Reader.
Replacing an access control device
1. Disconnect the cable between the access control device and the access actuator.
2. Remove screws from the bottom of the access control device and remove the access
control device from the baseplate.
3. Route the cable of the reserved access control device to the access actuator through a
cable hole along the original path.
4. Install the reserved access control device on the baseplate and secure the access control
device using screws at the bottom.
5. (Optional) After replacing an access control device with fingerprint functions, log in to
the WebUI to synchronize access parameters or record the user fingerprint information
again by performing the following steps.
a. Log in to the ECC800 WebUI and choose System Settings > Access Right
Management.
b. Select the user information and click Modify.
c. Record the fingerprint information again. Every user can record three fingerprints.
After the recording, click OK.
d. Choose System Settings > Access Right Management > Synchronize
Permission. Select the access control devices with modified permissions and
synchronize the access permissions.
Procedure for Replacing an IC Card Reader
1. Disconnect the cable between the card reader and the access actuator.
2. Remove screws from the bottom of the card reader cover and remove the card reader
cover.
3. Remove the two screws from the card reader and remove the card reader.
4. Take out the reserved card reader, remove the screws from the bottom of the card reader
cover, and then remove the cover.
