English-26
CONTROL PANEL
Control panel
On the top of the Auto Mower there is a control panel
under a cover. Open the cover by pressing the STOP
button. Close the cover by sliding it forward until a click
is heard. The click is heard when the STOP button
returns to the operating mode.
All forms of commands and settings for the Auto Mower
are made via the control panel. All functions are
accessed via a number of menus.
The control panel consists of a display and a keypad.
All information is shown on the display and all entry is
done using the buttons.
The main page shows the main menu, cursor, clock,
selected operating mode, number of mowing hours,
clock icon, program selection and battery status.
• The main menu is the uppermost level in the entire
menu structure.
• The cursor shows which menu has been selected
when the YES button is pressed.
• The clock shows the current time.
• The text AUTO or MAN shows which operating
mode has been selected.
• The number of operating hours indicates the num-
ber of hours since the day of manufacture that the
Auto Mower has been in operation. The time that
the Auto Mower has spent mowing or looking for the
charging station is counted as operating time.
• The clock icon shows when the Auto Mower should
be or is switched off by the timer, i.e. stands in the
charging station or is on its way to the charging sta-
tion to switch off.
• The program icon shows when one of the programs
under the buttons A, B or C is selected.
• The battery status shows the remaining battery
charge.
The keypad consists of five groups of buttons: Short-
cuts, program, selection, numbers and the main switch.
3012-283
Huvudmeny
Kommandon
Timer
Installation
Inställningar
3012-285
Main menu
Commands
Timer
Installation
Settings
3012-286
Huvudmeny
Kommandon
Timer
Installation
Inställningar
3012-239
