English-28
CONTROL PANEL
Select
6. Clr:
• Press to go back one step in the menu structure.
7. YES
• Press to confirm an entry or selection.
• Press to start the mower if more than 10 sec-
onds has elapsed since you last pressed a but-
ton and you want to close the control panel
cover.
8. Arrows
• Press any of the arrow buttons to browse
between menus or different selections.
Numbers
9. Used in the menu structure to enter settings, for
example, PIN code, time or exit direction.
Also used to state a number series as a shortcut
to the different menus. See more about number
series in ”Number series” on page 29.
Main switch
10. Set the main switch in the ”ON” position to start
the Auto Mower.
Set the main switch in the ”OFF” position when
you are not using the mower or if you want to work
on the blade disc.
When the main switch is set in the ”OFF” position
the motors on the mower cannot start.
When the main switch is turned ON for the first
time, a start-up sequence begins which includes:
selection of the language, time format, date format
and four digit PIN code as well as setting of the
time and date, see page 25.
3012-242
6
7
8
3012-243
ON
OFF
3012-244
10
