PRESENTATION
Presentation
Congratulations on your choice of an exceptionally
high quality product.
To get the best from your Auto Mower requires knowl-
edge of its function. This chapter contains information
you should be aware of when planning the installation.
Installation of the Husqvarna Auto Mower includes four
main components:
Auto Mower
, an automatic lawn mower that mows the
lawn by moving in essentially an irregular pattern. The
mower is powered by a maintenance free battery
Charging station
, where your Auto Mower returns
when the charge level in the battery becomes too low.
The charging station has three functions:
• To send control signals along the boundary wire.
• To send out signals so the Auto Mower finds the
charging station.
• To charge the Auto Mower battery.
Transformer
, which is connected between the charg-
ing station and a 230 V wall socket. The transformer is
connected to the wall socket via an integrated power
cord and to the charging station via a 20 m long low
voltage cable. The length of the low voltage cable must
not be changed.
Boundary wire
, laid in a loop around the Auto Mower’s
working area. The wire is laid around the edges of the
lawn and around objects and plants that the mower
must not run into.
The length of boundary wire needed in an installation
is the circumference of the working area plus a few
extra metres to lay around ”islands”, objects and
plants. A few extra metres are also required for any
subsequent adjustments. The boundary wire supplied
for the installation is 250 m long. If this is not sufficient
more wire can be purchased, with a connector, and
spliced onto the existing wire.
3012-278
3012-216
3012-220
3012-221
