MAINTENANCE
5-54 HPR130 Manual Gas Instruction Manual
6
Timeline Component Part number Qty.
6 months or 300 arc hours
Coolant filter element
Coolant solution 70/30
Torch kit
Quick-disconnect kit
027664
028872
128879
128880
1
4
1
1
1 Year or 600 arc hours
Coolant filter element
Coolant solution 70/30
Main contactor
Torch main body
Pilot arc relay
027664
028872
003139
220162
003149
1
4
1
1
1
1.5 Years or 900 arc hours+
Coolant filter element
Coolant solution 70/30
Torch kit
Quick-disconnect kit
027664
028872
128879
128880
1
4
1
1
2 Years or 1200 arc hours
Coolant filter element
Coolant solution 70/30
Main contactor
Torch main body
Pilot arc relay
Coolant pump kit
Torch leads
027664
028872
003139
220162
003149
128384
System dependent
1
4
1
1
1
1
1
2.5 Years or 1500 arc hours
Coolant filter element
Coolant solution 70/30
Torch kit
Quick-disconnect kit
027664
028872
128879
128880
1
4
1
1
3 Years or 1800 arc hours
Coolant filter element
Coolant solution 70/30
Main contactor
Torch main body
Pilot arc relay
Cooling fan 6"
Cooling fan 10"
027664
028872
003139
220162
003149
127039
027079
1
4
1
1
1
2
1
3.5 Years or 2100 arc hours
Coolant filter element
Coolant solution 70/30
Torch kit
Quick-disconnect kit
027664
028872
128879
128880
1
4
1
1
4 Years or 2400 arc hours
Coolant filter element
Coolant solution 70/30
Main contactor
Torch main body
Pilot arc relay
Coolant pump kit
Torch leads
Coolant pump motor kit
027664
028872
003139
220162
003149
128384
System dependent
128385
1
4
1
1
1
1
1
1
4.5 Years or 2700 arc hours
Coolant filter element
Coolant solution 70/30
Torch kit
Quick-disconnect kit
027664
028872
128879
128880
1
4
1
1
Service parts replacement schedule – 1 of 2
228015 – annual preventive maintenance parts kit
This kit includes all the parts in the shaded boxes below

Hypertherm HPR130 Specifications

General

Duty Cycle	100% at 130 A
Input Power	25.5 kVA @ 400 V
Weight	309 lb (140 kg)
Dimensions (H x W x D)	43.5 in x 23.5 in x 29.5 in (1105 mm x 597 mm x 749 mm)
Cutting Capacity (Mild Steel)	38 mm
Output Current	130 A
Gas Types	Air, Nitrogen, Oxygen
Cutting Speed	Up to 20 m/min
Cutting Method	Plasma
