4-36 MAX200 Instruction Manual
9-99
OPERATION
PAC200T/PAC200E Hand Torch
Aluminum
200 amps
•
N
2
Plasma / CO
2
Shield
This gas combination is used when cut edge quality is less important. lectrode life is extended when this
combination is used.
Piercing above 7/8 inch (22 mm) not recommended.
* If leads are greater than 50 feet, increase TEST pressure 5 psi for every extra 50 feet of torch lead length.
Plasma
Gas
Type
Plasma Gas
Pressure
TEST/RUN
Shield
Gas
Type
Shield
Gas
Pressure
Arc
Current
Setting
Arc
Voltage
Setting
Approx.
Motion
Delay Time
Plasma
Gas Inlet
Pressure
Shield
Gas Inlet
Pressure
(Inches) (mm) (psi) (psi) (Inches) (mm) (amps) (volts) (ipm) (mm/min) (sec) (psi) (psi)
3/16 5
N
2
36-40* / 52-56
CO
2
70 1/8 3 200 130 185 4700 0.5 120 90
1/4 6 1/8 3 135 160 4050 1.0
3/8 10 1/8 3 135 120 3050 2.0
1/2 12 1/8 3 140 95 2400 2.5
5/8 15 .157 4 140 70 1800 2.5
3/4 20 3/16 5 150 55 1400 3.0
7/8 22 1/4 6 160 42 1050 3.0
1 25 1/4 6 165 33 840
1-1/4 32 1/4 6 175 20 510
1-1/2 38 5/16 8 185 11 280
Material
Thickness
Torch-to-work
Distance
Travel Speed
(60 SCFH) (220 SCFH)
020918
Shield
020608
Nozzle
020915
Retaining cap
020415
Electrode
020607
Swirl ring
