4-38 MAX200 Instruction Manual
9-99
OPERATION
Piercing above 1/2 inch (12 mm) not recommended.
* If leads are greater than 50 feet, increase TEST pressure 5 psi for every extra 50 feet of torch lead length.
PAC200T/PAC200E Hand Torch
Aluminum
100 amps
H35 Plasma / N
2
Shield
This gas combination gives good cut speed, low dross levels and is very economical.
Plasma
Gas
Type
Plasma Gas
Pressure
TEST/RUN
Shield
Gas
Type
Shield
Gas
Pressure
Arc
Current
Setting
Arc
Voltage
Setting
Approx.
Motion
Delay Time
Plasma
Gas Inlet
Pressure
Shield
Gas Inlet
Pressure
(Inches) (mm) (psi) (psi) (Inches) (mm) (amps) (volts) (ipm) (mm/min) (sec) (psi) (psi)
1/8 3 H35 32-36* / 56-60
N
2
60 5/64 2 100 135 95 2440 120 90
3/16 5 1/8 3 140 85 2200 0.5
1/4 6 1/8 3 145 80 1980 0.5
3/8 10 1/8 3 145 60 1530 0.5
1/2 12 1/8 3 150 50 1280
Material
Thickness
Torch-to-work
Distance
Travel Speed
(20 SCFH) (270 SCFH)
020919
Shield
020611
Nozzle
020915
Retaining cap
020415
Electrode
020607
Swirl ring
