Powermax30 XP Service Manual 808150 Revision 0 197
8 – Parts
Recommended spare parts
Hypertherm recommends that service centers keep the following spare parts on hand for repairs because these parts are
critical or are usually exposed to heavy and repeated wear. You may find that you need to revise or expand this list for your
customers, based on the conditions and work environments in your region.
7 228210 Kit: CSA power cord with NEMA twist lock-style 240 V/20 A plug, 1-phase, 3.0 m
(10 feet)
8 228140 Kit: CE power cord, 1-phase, 3.0 m (10 feet) (plug not included)
8 428231 Kit: CCC power cord, 1-phase, 3.0 m (10 feet) (plug not included)
9 228143 Kit: Power cord strain relief
Kit Number Description Reference
428226 Kit: Current adjustment knob page 186
228561 Kit: Ground clamp page 186
428239 Kit: Work lead, 4.6 m (15 feet) (includes ground clamp) page 186
428235 Kit: Power switch page 188
428232 Kit: Control board page 188
428233 Kit: Power board, CSA page 188
428234 Kit: Power board, CE and CCC page 188
428173 Kit: Solenoid valve page 190
228688 Kit: Pressure switch page 190
228106 Kit: Air filter/regulator with pressure switch page 190
428237 Kit: Air filter element page 190
428179 Kit: Replacement o-rings for torch body page 193
428177 Kit: Duramax LT torch handle page 193
428181 Kit: Duramax LT torch handle screws page 193
428156 Kit: Torch trigger and spring page 193
428182 Kit: Spring for torch trigger page 193
428162 Kit: Torch start switch page 193
228109 Kit: Torch cap-sensor switch page 193
428174 Kit: Duramax LT hand torch assembly with 4.6 m (15 foot) lead page 193
428176 Kit: Duramax LT torch lead, 4.6 m (15 feet) page 193
128836 Thermal grease, 1/8 ounce page 195
027055 Silicone lubricant, 1/4 ounce page 195
Item Kit number Description
