3-28
MAINTENANCE
powermax600 Service Manual
Removal
• Disconnect electrical power.
• Disconnect gas supply.
• Remove the power supply cover.
Air Filter Element Replacement
Refer to Figure 3-12.
Figure 3-12 Air Filter Element Removal
Unscrew the filter bowl.
Do not discard the O-ring.
Remove the filter element
from the filter housing.
NOTE: Do not allow the filter element
to turn when loosening the screw.
Compress the hose fitting collar and
pull the gas hose from the hose fitting.
Pull the drain hose from the grommet
in the floor of the power supply.
10-99
