powermax600 Service Manual
PARTS LIST - 400/230V CE
RECOMMENDED SPARE PARTS - POWERMAX600- 230/400V
Part Number Description Page
Reference
001668 ............................... Front end panel............................................................................. 4-2
001669 ............................... Rear end panel ............................................................................. 4-2
008965 ............................... Knob ............................................................................................. 4-2
110242 ............................... Operation lable ............................................................................. 4-2
110258 ............................... Instruction label............................................................................. 4-2
110261 ............................... Warning label ................................................................................ 4-2
129488 ............................... Power supply cover ...................................................................... 4-2
041593 ............................... Control PCB assembly.................................................................. 4-3
108090 ............................... Terminal block .............................................................................. 4-3
123375 ............................... Work Cable with clamp, 4.6 m/15 ft .............................................. 4-3
129374 ............................... Solenoid valve .............................................................................. 4-3
003193 ............................... Circuit breaker, 400 V ................................................................... 4-4
003195 ............................... Circuit breaker, 230 V ................................................................... 4-4
041566 ............................... EMI Filter PCB, 400 V................................................................... 4-4
041587 ............................... EMI Filter PCB, 230 V................................................................... 4-4
129368 ............................... Power cable, 400 V....................................................................... 4-4
129410 ............................... Power cable, 230 V....................................................................... 4-4
005112 ............................... Pressure Switch ............................................................................ 4-5
009999 ............................... Capacitor, 1800/1900UF, 400V .................................................... 4-5
011083 ............................... Filter regulator subassembly......................................................... 4-5
011086 ............................... Air filter element ............................................................................ 4-5
011087 ............................... O-ring, Air filter element ................................................................ 4-5
014231 ............................... Inductor, input choke 5MH 11A, 400V .......................................... 4-5
014232 ............................... Inductor, output choke .80MH 40A ............................................... 4-5
014234 ............................... Power transformer, 400V .............................................................. 4-5
014238 ............................... Power transformer, 230V .............................................................. 4-5
014241 ............................... Inductor, input choke 5MH 11A, 230V .......................................... 4-5
022027 ............................... Pressure gauge ............................................................................ 4-5
109118 ............................... Capacitor, 1800/1900UF, 230V .................................................... 4-5
129366 ............................... Fan subassembly.......................................................................... 4-5
005222 ............................... Temp switch.................................................................................. 4-6
009849 ............................... Resistor, 20 OHM ......................................................................... 4-6
041568 ............................... Power PCB, 400V ......................................................................... 4-6
041607 ............................... Power PCB, 230V ......................................................................... 4-6
109067 ............................... MOV.............................................................................................. 4-6
109079 ............................... IGBT module................................................................................. 4-6
109080 ............................... IGBT, pilot arc ............................................................................... 4-6
109088 ............................... Output diode ................................................................................. 4-6
109090 ............................... Input diode bridge, 400V............................................................... 4-6
109134 ............................... Input diode bridge, 230V............................................................... 4-6
129406 ............................... EMI suppression capacitor ........................................................... 4-6
027662 ............................... Thermal grease, 5 oz. DC-340 ..................................................... 4-6
008903 ............................... Thermal pad.................................................................................. 4-6
