3-51
Convenient features of your vehicle
3
Gauges and meters
Speedometer
The speedometer indicates the speed
of the vehicle and is calibrated in kilo-
meters per hour (km/h) and/or miles
per hour (MPH).
Tachometer
The tachometer indicates the approxi-
mate number of engine revolutions per
minute (rpm).
Use the tachometer to select the cor-
rect shift points and to prevent lugging
and/or over-revving the engine.
Do not operate the engine within
the tachometer's RED ZONE. This
may cause severe engine damage.
Engine Coolant Temperature
Gauge
This gauge indicates the tempera-
ture of the engine coolant when the
ignition switch is in the ON position.
NOTICE
OAD048106N/OAD048107N
■ Conventional/
Supervision cluster
(Type A, B)
■ Supervision cluster
(Type C)
• MPH, km/h
• km/h
■ Conventional/Supervision cluster (Type A, B)
OAD046519/OAD046520
• MPH, km/h
• km/h
■ Supervision cluster (Type C)
OAD048104L/OAD048104N
• For Europe
• Except Europe
■ Conventional/Supervision cluster (Type A, B)
OAD046522/OAD046523
• For Europe
• Except Europe
■ Supervision cluster (Type C)
OAD048543N/OAD048543L
