Flush-front mounting
NOTE
Use the screws specified for use with the device. Longer screws can damage the device.
Flush-front mounting
NOTE
The device must be turned off and disconnected from the fabric during this procedure.
NOTE
The illustrations in this document show a 1U device, but the instructions are the same for a 2U device.
Complete the following tasks to install the device in a four-post rack:
1. Attaching the front brackets on page 29
2. Attaching the extension brackets to the device on page 30
3. Installing the device in the rack on page 31
4. Attaching the rear brackets to the extensions on page 32
5. Attaching the rear brackets to the rack posts on page 33
Attaching
the
front
brackets
Complete the following steps to attach the front brackets to the device.
1. Position the right front bracket with the flat side against the right side of the device at the front of the
device, as shown in Figure 4 .
2. Insert four 8-32 x 5/16-in. flathead screws through the vertically aligned holes in the bracket and then
into the holes on the side of the device. Use the upper and lower screw holes, leaving the center
holes empty.
3. Repeat step 1 and step 2 to attach the left front bracket to the left side of the device.
4. Tighten all the 8-32 x 5/16-in. screws to a torque of 15 in-lb (17 cm-kg).
Hardware Installation Guide 29
