Installing the Transceivers and Cables
● Time and items required................................................................................................. 59
● Precautions specific to transceivers and cables............................................................. 60
● Cleaning the fiber-optic connectors.................................................................................60
● Managing cables............................................................................................................. 60
● Installing an SFP+ transceiver........................................................................................ 61
● Replacing an SFP+ transceiver.......................................................................................62
● Installing a QSFP transceiver..........................................................................................63
● Replacing a QSFP transceiver........................................................................................ 64
● Verifying the operation of new transceivers.................................................................... 65
Time and items required
The installation or replacement procedure for one transceiver takes less than five minutes. Ensure that
the following items are available:
• Required number of compatible power cables
• Required number of supported Brocade-branded transceivers
Refer to the Fabric OS Release Notes for the list of supported transceivers and cables.
• Required number of compatible fiber-optic cables
• Optical transceiver extraction tool (for 10-Gbps transceiver only)
NOTE
Most switches and backbones come with a transceiver extraction tool and holster. The
extraction tool is designed to remove transceivers from modules where the space is limited.
FIGURE 24 Optical transceiver extraction tool
Hardware Installation Guide 59
