System status LED
TABLE 9
System power LED patterns during normal operation
LED color Status of hardware Recommended action
No light System is off or there is an internal
power supply failure.
Verify that system is powered on,
the power cables attached, and your
power source is live.
If the system power LED is not
green, the unit may be faulty.
Contact your solution provider.
Steady green System is on and power supplies
are functioning properly.
No action required.
System status LED
Refer to the following table to interpret the system status LED.
TABLE 10
System status LED patterns during normal operation
LED color Status of hardware Recommended action
No light System is off or there is no power. Verify that system is on and has
completed booting.
Steady green POST and initialization is
completed. System is on and
functioning properly.
No action required.
Steady amber (for more than five
seconds—can take over a minute to
complete POST)
System is going through the power-
up process.
No action required.
Steady amber (for more than a few
minutes)
Unknown state, boot failed, or the
system is faulty.
NOTE
Once POST completes and the
switch has failed, steady amber may
result.
Perform the following steps:
1. Connect a serial cable to the
system.
2. Reboot the system.
3. Check the failure indicated on the
system console
4. Contact your solution provider.
Flashing amber/green Attention is required. A number of
variables can cause this status,
including a single power supply
failure, a fan failure, or one or more
environmental ranges have been
exceeded.
Check the management interface
and the error log for details on the
cause of the status.
Contact your solution provider.
68 Hardware Installation Guide
