154
12 -12Vdc Blue
13 Ground Black
14 Power On Green
15 Ground Black
16 Ground Black
17 Ground Black
18 -- --
19 +5Vdc Red
20 +5Vdc Red
Power Supply Output Pin Assignment
(Continued)
Pin Voltage Cable Color
