Parts Catalog 199
Assembly 1b: Machine Type 2172 System Unit - Exterior
Asm-
Index
FRU Number Description
1b-1 00K8479 Top/Side Panel w/ handle, Black
1b-1 02K2324 Top/Side Panel w/ handle, White
1b-2 00K8480 Front Panel, Black
1b-2 02K2325 Front Panel, White
1b-3 00K8478 Top Cover, Black
1b-3 02K2326 Top Cover, White
1b-7 00K8481 Drive Bay Panel (2nd and 3rd 5.25” drive), Black
1b-7 02K2330 Drive Bay Panel (2nd & 3rd 5.25" drive), White
1b-8 00K8482 Drive Bay Panel (First 5.25” drive), Black
1b-8 02K2331 Drive Bay Panel (First 5.25" drive), White
