IBM iSeries 800 Analyze Hardware Problems (System Reference Codes

(B467) System Processor Reference Codes
The system processor detected a failure.
Note: This procedure applies only to system Models 840 and SB3.
Collect data from Functions 11, 12, and 13 of the system panel, or words 1 through
9 from the Main Store Dump (MSD) screen. This SRC, beginning with ″B4″, may
contain up to five FRUs. Eight characters of this data represent a single FRU. The
FRU characters have two parts: a unit reference code, and a type number. The
location of this data is shown below:
PANEL FUNC 11: B4xx____ RC01TP01
RC02RC03 RC04RC05
PANEL FUNC 12: DATA0012 DATA0013
TP02TP03 TP04TP05
PANEL FUNC 13: DATA0016 DATA0017
DATA0018 DATA0019
The FRU information for FRU 1 would be RC01 and TP01, for FRU 2 would be
RC02 and TP02, etc.
Characters Description / Meaning Length
RC01 FRU 1 - Ref Code 4 Characters
TP01 FRU 1 - Type 4 Characters
RC02 FRU 2 - Ref Code 4 Characters
TP02 FRU 2 - Type 4 Characters
RC03, TP03, RC04, TP04, RC05, TP05 same as above.
DATA012, DATA013,
DATA016, DATA017,
DATA018, DATA019
Miscellaneous Data - Not applicable, but
may be needed for your next level of
support.
8 Characters
The example below shows relevant data for three FRUs:
RC01=5200, TP01=245E, RC02=8100, TP02=3197, RC03=9300, TP03=25AA,
the remaining values are zeroes.
PANEL FUNC 11: B467____ 5200245E
81009300 00000000
PANEL FUNC 12: xxxxxxxx xxxxxxxx
319725AA 00000000
PANEL FUNC 13: xxxxxxxx xxxxxxxx
xxxxxxxx xxxxxxxx
Characters Description / Meaning Length
5200 FRU 1 - Ref Code = 5200 4 Characters
245E FRU 1 - Type = 245E 4 Characters
8100 FRU 2 - Ref Code = 8100 4 Characters
3197 FRU 2 - Type = 3197 4 Characters
9300 FRU 3 - Ref Code = 9300 4 Characters
25AA FRU 3 - Type = 25AA 4 Characters
B467
254
iSeries: iSeries 270, 800, 810, 820, 825, 830, 840, 870, 890, SB2, and SB3 Analyze Hardware Problems (System Reference
Codes)
