IBM iSeries 800 Hardware Problem Analysis And Isolation

Unit reference code FRU description / CCIN Location
xD0A L3 cache card / 25F1 M10
xD0B L3 cache card / 25F1 M12
xD0C L3 cache card / 25F1 M03
xD0D L3 cache card / 25F1 M09
xD0E L3 cache card / 25F1 M19
xD0F L3 cache card / 25F1 M26
x007 L3 cache card VPD / 25F1 M41- C
Table 21. Network Interface Controller (NIC) card information for Models 800, 810, 825, 870, and 890
Model
Unit
reference
code
Processor feature
code HSL controller type Location
800, 810 4600, 8600,
C600, 5100,
9100, or
D100
All 25F0, 25B9, 25BA MB1
825 x00C All 2785, 2786 C09
825 x00B All 2785, 2786 C08
825 x00A All 28B3 MB1
870, 890 x00D All 2776, 2788 M39
870, 890 x00C All 2776, 2788 M30
870, 890 x00B All 2776, 2788 M40
870, 890 x00A All 2738 M41
CDAWKLD
For use by authorized service providers.
Too many communications lines are in use.
CDTRAY
For use by authorized service providers.
This symbolic FRU is not supported.
CECPWR
For use by authorized service providers.
The failing item is the power supply for the system unit.
1. Choose from the following options:
v If you are on a Model 270 or 820: Continue with the next step.
v If you are on a Model 830, 840, SB2, or SB3: Go to step 5 (See page 319).
2.
Is this a Model 270 system unit, with processor feature 22A2, 22A4, 22A5 or 2422?
v Yes: See Locations — Model 270. Replace the following FRUs in order one at a time until the
problem is resolved.
Note: Be sure to IPL in SLOW OVERRIDE mode after each replacement.
a. Power regulator in location R01
318 iSeries: iSeries Server 270, 800, 810, 820, 825, 830, 840, 870, 890, SB2, and SB3 Hardware Problem Analysis and
Isolation
