RC0x Value Location for Model 825
Location for
Models 870 and 890
x020 M02-C M18-A (control card)
x021 M02-A M24-A (control card)
x022 M02-D M07-A (control card)
x023 M02-A M02-A (control card)
x024 M02-G M25-A (control card)
x025 M02-E M08-A (control card)
x026 M02-H M01-A (control card)
x027 M02-F M17-A (control card)
xD00 NA M27
xD01 NA M28
xD02 NA M22
xD03 NA M20
xD04 NA M29
xD05 NA M06
xD06 NA M13
xD07 NA M23
xD08 NA M05
xD09 NA M04
xD0A NA M10
xD0B NA M12
xD0C NA M03
xD0D NA M26
xD0E NA M19
xD0F NA M09
4. If replacing the possible failing items from the SRC does not correct the problem, replace the J-Tag
Cable. See Power and signal cables.
5. If the problem persists, replace the Service Processor.
v For Model 825, the Service Processor is part of the System Unit Backplane in location MB1. See
Model 825 - System unit backplane (MB1)
v For Models 870 and 890, the Service Processor is part of the Tower Card in the Base I/O Unit in
location CB1. See Models 870 and 890 (FC 9094) - Tower card - CB1.
6.
If the problem still persists, call your next level of support.
For locations and removal and replacement information about possible failing items, see Locations —
Model 825 or Locations — Models 870 and 890 with an FC 9094 Base I/O Tower.
This ends the procedure.
LBSADP1
For use by authorized service providers.
The failing item is a combination HSL I/O bridge card and local bus adapter card in an FC 5077 SPD
migrated tower. Go to symbolic FRU LBSADP1 in the Migrated Expansion Tower Problem Analysis, Repair
and Parts manual on the V5R1 Supplemental Manuals web site
for information on servicing this
failing item.
358 iSeries: iSeries Server 270, 800, 810, 820, 825, 830, 840, 870, 890, SB2, and SB3 Hardware Problem Analysis and
Isolation
