b. Replace each card one at a time, powering on the system or tower (as instructed in the remove
and replace procedure) after you replace each one, until the problem appears again. The last
card that you replaced before the problem appeared again is the failing item. Continue with the
next step.
3.
Use the links in the table below to locate and replace the failing item.
Table 1. Failing item for symbolic FRU PIOCARD
System model, tower, expansion
unit, or machine type Name of FRU to exchange
Link to locations information and
remove and replace procedures
Model 270
(Embedded IOP DSA = 000110xx)
System unit backplane See Locations - Model 270.
You will need the processor feature
code (characters 5 through 8 of function
20 on the control panel).
Model 270 PCI IOP or IOA See Locations - Model 270.
You will need the processor feature
code (characters 5 through 8 of function
20 on the control panel).
Models 800 and 810 System unit backplane See Locations - Models 800 and 810
You will need the processor feature
code (characters 5 through 8 of function
20 on the control panel).
Models 800 and 810 PCI IOP or IOA See Locations - Models 800 and 810
Model 820
(Embedded IOP DSA = 000110xx)
System unit backplane See Locations - Model 820
Model 820 PCI IOP or IOA See Locations - Model 820
Model 825 PCI IOP or IOA See Locations - Model 825
Models 830 and SB2 base I/O tower
(FC 9074)
PCI IOP or IOA See Locations - Models 830/SB2
System Unit with FC 9074 Base I/O
Tower
Models 840 and SB3 base I/O tower
(FC 9079)
PCI IOP or IOA See Locations - Models 840/SB3
system unit with processor tower and
FC 9079 base I/O tower
Models 870 and 890 PCI IOP or IOA See Locations - Models 870 and 890
FC 5074 Expansion I/O Tower PCI IOP or IOA See Locations - FC 5074 Expansion I/O
Tower
FC 5075 Expansion I/O Tower PCI IOP or IOA See Locations - FC 5075 Expansion I/O
Tower
FC 5078, FC 0578 Expansion I/O Unit PCI IOP or IOA See Locations - FC 5078, 0578
Expansion I/O Unit
FC 5079 (1.8m expansion tower) PCI IOP or IOA See Locations - FC 5079 Expansion I/O
Tower
FC 5088 or FC 0588 Expansion I/O
Unit
PCI IOP or IOA See Locations - FC 5088, FC 0588
Expansion I/O Unit
FC 5095, FC 0595 Expansion I/O Unit PCI IOP or IOA See Locations - FC 5095, FC 0595
Expansion I/O unit
External xSeries Server Integrated xSeries Adapter Card See Locations - Integrated xSeries
adapter card (IXA).
This ends the procedure.
PLUS
For use by authorized service providers.
416 iSeries: iSeries Server 270, 800, 810, 820, 825, 830, 840, 870, 890, SB2, and SB3 Hardware Problem Analysis and
Isolation
