IBM iSeries 820 Hardware Problem Analysis And Isolation

Follow the instructions for the model you are working on:
v Models 270 and 820 (See page 465)
v Models 800, 810, 825, 830, 840, 870, 890, SB2, and SB3 (See page 466)
Instructions for Models 270 and 820
1. Choose one of the following:
v If you are working on a Model 820, use Table 1. below to determine the service information.
This
ends the procedure.
v If you are working on a Model 270, continue with the next step.
2.
Is function 20 available on the system unit control panel?
v No: Continue with the next step.
v Yes: Select function 20 on the system unit control panel. Record the processor feature code
(characters 5 through 8). Use Table 1. below to determine the service information.
This
ends the procedure.
3. The system unit backplane is in position MB1. To determine which system unit backplane is installed,
remove the cover on the left side. See Models 270, 800, 810 - Covers. Then, continue with the next
step.
4. Examine the card positions on the system unit backplane.
v If there are card positions labeled M01 and M02, then you are working on a Model 270 with a
Network Interface Controller (NIC) embedded in the processor card.
v If there are no card positions labeled M01 and M02, then you are working on a Model 270 with a
Network Interface Controller (NIC) embedded in the system unit backplane.
Table 1. Service information for Models 270 and 820
System model Name of FRU to exchange FRU position
Link to failing component
service information (CCIN,
locations diagram,
remove and replace
procedure)
Model 270 System unit backplane MB1 Go to Locations - Model
270 and follow links for
either the processor feature
code or what FRU the NIC
is embedded in. (The
processor feature code is
characters 5 through 8 of
function 20 on the control
panel.)
Model 820 System unit backplane MB1 See Locations - Model 820.
FC 5065, FC 5066 Expansion unit backplane CB1 See Locations - FC 5074
Expansion I/O Tower.
Note: Position CB1 is the
same on the FC 5074, FC
5065, and FC 5066.
FC 5074, FC 5079 Expansion unit backplane CB1 See Locations - FC 5074
Expansion I/O Tower or
Locations - FC 5079
Expansion I/O Tower.
FC 5075 Expansion unit backplane CB1 See Locations - FC 5075
Expansion I/O Tower.
Analyze hardware problems 465
