Table 41. FCs for the frame models of the TS4500 tape library (continued)
FC Model CSU Description
AGKQ 3 Meter OM3 Fiber Quad Cables (LC),
D25, D55, L25, L55
Yes Provides 2 space-efficient 3m bundles (of
four cables each) to connect four drives to
a fiber switch in the same or one frame
away,or in a TR1 top-rack.
To attach TS4500 tape drives in the same
frame or 1 frame away from a model x25
frame containing TS7700 BE switches,
order one of this feature code for each
quad-drive mounting kit to be connected.
For xx5 models, each FC AGKQ has a
prerequisite of an associated FC 152x .
Frame capacity
The cartridge capacity of the frames of the TS4500 tape library varies depending on
whether the frame has I/O stations, tape drives, or any of the available capacity on
demand features that increase the amount of licensed capacity of the frame.
Capacity of L25, D25, and S25 frames
The position and configuration of the frame, and the installation of capacity on
demand (CoD) features, affect the total available capacity of the L25, D25, and S25
frames.
Table 42 shows available storage capacity based on possible frame positions and
configurations.
Table 42. Quantity of storage slots in L25, D25, and S25 frames
Frame model
Licensed
feature(s)
Frame
position
Quantity of
drives
Quantity of
I/O slots
Quantity of
storage slots
L25 Entry 1 1 to 12 32 100
Intermediate
CoD
1 1 to 12 32 200
Base CoD 1 0 to 12 32 400
Base CoD 2+ 0 to 16 32 400
HD CoD 1 0 to 12 32 550
HD CoD 2+ 0 to 16 32 660
D25 Base 1 0 to 12 0 or 32 500
Base 2+ 0 to 16 0 or 32 500
HD CoD 1 0 to 12 32 550
HD CoD 1 0 to 12 0 590
HD CoD 2+ 0 to 16 32 660
HD CoD 2+ 0 to 16 0 740
S25 Base Any 0 0 600
HD CoD 1 0 0 798
HD CoD 2+ 0 0 1000
Chapter 2. Planning 109
