Fig. 50 - Front View EXALT Solo 155

104

CHAPTER 19

CHAPTER 19 - PRODUCT SPECIFICATIONS

A B C D E F G H I J K

Item

Boiler

Width

3" Com-

bustion Air

Inlet

3" Vent

Outlet

/" NSPC

Relief

Valve

Vent\Com-

bustion Air

Connection

Height

Boiler

Height

1" NPT

Boiler

Supply

1" NPT

Boiler

Return

/" Gas

Connection

Conden-

sate Drain

Conden-

sate Height

Dimension

inches

[mm]

21 /

[550]

15 /

[400]

4 /

[120]

2 /

[55]

5 /

[130]

[660]

1 /

[48]

2 /

[70]

4 /

[110]

4 /

[120]

6 /

[171]
