105

CHAPTER 19

L M N O P Q R

Items

/" NPSC

Relief Valve

3"Combustion

Air Inlet & 3"Vent

Outlet

1" NPT Boiler

Return

Condensate

Drain

1" NPT Boiler

Supply

/" NPT

Gas Connection

Boiler Depth

Dimension

inches

[mm]

8 /

[220]

3 /

[80]

9 /

[230]

3 /

[80]

6 /

[165]

11 /

[285]

17 /

[435]

CHAPTER 19 - PRODUCT SPECIFICATIONS

Fig. 51 - Right Side View EXALT Solo 155

Default Chapter3
- Table of Contents3
